Description

Raw materials are mixed and then molded. Heat treatment is then applied in the baking and graphitization process to form the finished product.

Introduction

Physical & Chemical Properties of HP Graphite Electrodes


Items

Classification

Unit

Nominal Diameter (mm)

HP Graphite Electrode

200-400

450-500

550-600

Resistivity

Electrode

μΩm

7.0

7.5

7.5

Nipple

6.3

6.3

6.3

Bending Strength

Electrode

Mpa

10.5

10.0

8.5

Nipple

17.0

17.0

17.0

Young’s Modulus

Electrode

Gpa

14.0

14.0

14.0

Nipple

16.0

16.0

16.0

Bulk Density

Electrode

g/cm3

1.60

1.60

1.60

Nipple

1.72

1.72

1.72

CTE100℃-600℃

Electrode

×10-6/℃

2.4

2.4

2.4

Nipple

2.2

2.2

2.2

Ash Content

Electrode

%

0.5

0.5

0.5

Nipple


Note: Ash Content is only for reference.


Grade

Nominal Dia.

Allowable current  A

Current density  A/cm2

HP electrode

200mm

55009000

1825

250mm

800013000

1825

300mm

1300017400

1724

350mm

1740024000

1724

400mm

2100031000

1624

450mm

2500040000

1524

500mm

3000048000

1524

550mm

3400053000

1422

600mm

3800058000

1321


Advantage

  • 1 Year Warranty We can provide very professional commercial support, technical support and document support
  • 18 Years Experience We have extensive export experience in graphite products.
  • R&D Design Team Professional design and development team to provide you with professional and reasonable graphite product usage solutions
  • Quality Control Rigorous quality control process, each process process traceable, to provide customers with high quality products
